Removable Bottom Feature

INSTALLATION

• Using a 7/16 wrench for the nuts and a 7/16 ratchet for the exterior bolts, loosen the four bolts securing the bottom platform. Remove side panels if needed for easier access to the nuts.

1. Carefully lift the box off the bottom platform.
2. Set your generator onto the platform, ensuring it is properly positioned.
3. Secure the generator to the platform using the provided nylon strap.
4. Place the box over the generator, aligning it with the platform.
5. Reattach the box to the platform by bolting it back together with the provided hardware.

Key Points

The removable bottom feature provides both flexibility and convenience for installation and maintenance, allowing users access to the generator to make adjustments or repairs much more manageable.

This design allows you to mount the equipment on a standard rack, a custom rack, or any preferred location, giving you greater versatility in your setup.

Another important advantage of the removable bottom is that it eliminates the need to lift the entire box with the generator inside.

Hardware:

4 - ¼ - 20 bolts

4 - ¼ - 20 Nylock nuts

8 - Washers

1 - Nylon Cam Buckle Strap
